Topic News & Events - News

21

Jan

Cincon releases new 700W AC-DC Brick Power Supply– PDF700S series

The PDF700S series is our new 700W, innovative high-density, class I, AC-DC power module in an industrial standard Full Brick size (116.8x61.0x12.7mm). It has safety approvals for IEC/UL/EN 62368-1, and the AC-DC power supply series provides EMC compliance to meet EN55032 Level A for conducted, and radiated emissions as well as offer immunity to meet EN55035. With the input range of 90~264Vac and the Power Factor Correction (PFC), this series comes in 5 different outputs of 12, 24, 28, 48 and 56VDC.

#Product Press Release #AC-DC Power Supply #Industrial / ITE #Baseplate-cooling / Fanless

14

Jan

The Solution of Cincon High Input Voltage DC-DC Converters

Cincon offers a variety of high input voltage DC-DC converters from 150W-750W in industry standard quarter, half and full brick sizes. They provide a 300Vdc nominal input (with an input range of 180 to 425Vdc) and 3000VAC reinforced insulation, which are suitable for distributed power architectures, telecommunications, data centers, base station, battery operated equipment, and industrial applications.

#Technical Article #Featured Product Article #DC-DC Converter #Industrial / ITE #High Input Voltage

07

Jan

CHB200W12-72S for Railway Solution

With many years of professional experience, Cincon Electronics has launched many power converters that help our business partners to solve the challenges of power supply applications.

#Technical Article #DC-DC Converter #Railway #Industrial / ITE #Ultra-wide Input Range

10

Dec

The Ground Rules to Select and Build a Modular DC-DC Power System-III

In the previous articles, we discussed fundamental concepts and EMI consideration for building DC-DC modular system. In rare cases, the abnormal peak current flows in the modular system, which is at risk of damaging the whole power system. To avoid catastrophic situation, safety circuitry design for protecting the power system is quite important. In this article, we will discuss key points to select right Fuse and TVS (Transient Voltage Suppressor) for building front-end safety protection circuitry.

#Technical Article #DC-DC Converter #Railway #Industrial / ITE #Ultra-wide Input Range #High Input Voltage

03

Dec

The Application of Cincon AC-DC PFC module - PFC750

As the “energy saving” topic being mentioned frequently nowadays, power supply manufacturers keep chasing the high efficiency and low power consumption features.

#Technical Article #AC-DC Power Supply #Industrial / ITE #Baseplate-cooling / Fanless
